Xiegu X6100 HF Transceiver | Full Mode | SDR Radio

Write a review
SKU: 715-XH-X6100
  • Regular price $639.00
  • Regular price SAVE$-639.00

Only 208 left in stock



1. Analog – SDR Radio
Software-defined radio (SDR) system uses software for the modulation and demodulation of radio signals. Processing via a computer or other digital devices with software, the X6100 can provide you more info in real-time, complete complex operations and process data faster.

2. 5W Upgrade to 10W High Power
From 5W to max 10W, the Xiegu X6100 is a more powerful RIG than the X5105. In general, a higher wattage allows for greater range. Working with the XPA125B power amplifier, the X6100 can meet your long-rang talking requirement.

3. 3.6in LCD Screen - 4in Color Screen
The Xiegu X6100 HF transceiver comes with a 4-inch large color screen with 800*400 high resolution, helping you see all the important information at a glance.

4. Wireless Operation – Bluetooth, Wi-Fi, USB Host, Mouse, Keyboard Operation
In addition to traditional connecting ports to connect with extended devices , the Xiegu X6100 also supports modern connection methods like mouse and keyboard control via Bluetooth.

5. Voice Call | Preset Message | Digital Noise Reduction | Data Modem | SWR Scanner

6. Built-in High-stability TCXO Internal Clock Source

CLICK HERE to get the latest firmware & user manual.



2022.01.17 Upgrade Log | CLICK HERE to download.
PP : V1.1.2 Jan 17 2022,16:31:45
BASE : V1.1.2 Jan 17 2022,15:44:18
Note: This upgrade is important. Please read the following details carefully.

1. In-machine coulometer is enabled to manage battery cell. After the upgrade, the battery capacity, rather than battery voltage, measured by the coulometer is taken as management data. Precautions are as follows:
   1.1) After upgrading firmware, please fully charge and discharge the battery for successive 4 times, after which the measurement of the coulometer will be accurate.
After just upgrading the firmware, the error of electric quantity displayed is large before the 4 charges and discharges as mentioned above, so it can be ignored. The charging process shall be kept continuous until the charging instruction indicates it has been completed, which is conducive to the accurate measurement of the capacity by the coulometer.
   1.2) The status of the upgraded charging indicator light is as follows:
      Flashing: charging
      Normally on: charging completed
      Off: once the charging option is disabled in the menu, the indicator light will not be off.
   1.3) When the electric quantity is below 10% after the upgrade, the battery icon is displayed in red with an empty interior, and the device will automatically shut down.
   1.4) Battery voltage is no longer taken as the basis of low power.
2. Parameter adjustment in GEN menu is changed to non-circulating, which can be switch by rotating the large knob to left or right.
3. DFL menu logic is fixed. Press other menus to exit after entering DFL menu.
4. Preset message transmission function is added (available for W, PS and RTTY).
5. CW decoding algorithm is adjusted.
6. Start screen is changed to LOGO+model.
7. Bluetooth device connection logic is optimized (there has been feedback about poor compatibility with Windows 10/11 64bit drivers).
8. The problem that label of axis X scanned by SWR does not upgrade is fixed.
9. The bandwidth of first group of filter of SSB is widened to 50-2950Hz(2.9k).
10. The problem of save failure after adjusting the filter is fixed.
11. Indicator string under AGC mode is simplified to AGC-A,AGC-F,AGC-S,AGC--.
12. Indicator string 'FIL-X' of current filter bank is added, which is below VFO frequency.
13. LSB-DIG and USB-DIG strings are simplified to L-DIG and U-DIG.
14. Hand microphone button function is enabled.
   14.1) SPCH/LOCK: short press=lock/unlock larger impeller; long press=none
   14.2) TUNER/CALL: short press=switch on/disconnect automatic antenna tuner; long press=enable automatic antenna tuner
   14.3) XFC: short press=switch VFO A/B; long press=copy VFO from foreground to background
   14.4) V/M: short press=switch VFO/MEMO mode; long press=none
   14.5) MW: short press=save VFO to current channel number; long press=none
   14.6) MODE: short press=LSB->L-DIG->USB->U-DIG->CW->CWR->AM->NFM circulation; long press=none
   14.7) FIL: short press=FIL1->FIL2->FIL3 circulation; long press=none
   14.8) UP: frequency+stepping position under VFO mode; next channel under channel mode
   14.9) DOWN: frequency-stepping position under VFO mode; last channel under channel mode
   14.10) F1/F2: allow setting custom functions in RADIO SETTING2
15. Standingwave meter fluctuation under no power and low power conditions is fixed.
16. Maximum output power under external power supply condition is improved.
17. System startup sequence is optimized.
18. NR algorithm is optimized.
19. System data structure is optimized.
20. Display screen backlight adjustment level is optimized. There are 5 levels available when using battery and 10 levels available when using external power supply.

--- --- --- ---

2021.12.30 Upgrade Log | CLICK HERE to download.
App: Version number V1.1.2 Dec 30 2021,16:36:55
1. The frequency adjustment step is changed to 10, 100, 1000 Hz cycle.
2. The spectrum bandwidth is changed to 100kHz, 50kHz is adjustable in two levels.
3. Improved the Bluetooth scanning speed and shortened the time to scan peripheral devices after turning on Bluetooth.
4. Fixed the problem that the WIFI IP address and gateway address could not be displayed correctly.

Base: Version number V1.1.2 Dec 30 2021,15:37:48
1. Improved NR performance,the noise caused by the NR algorithm itself is eliminated.
2. Improved ALC performance,CW performance is improved.

--- --- --- ---

2021.12.29 Upgrade Log | CLICK HERE to download.
1. Added WIFI function
2. Added Bluetooth function
3. Fixed the bug that can not save the user selected filter group(1,2,3)
4. Optimized the ALC algorithm and corrected the problem of power rise slow.
5. Optimized the system settings.

--- --- --- ---

2021.12.07 Upgrade Log
| CLICK HERE to download.
1. Optimize the system audio configuration to eliminate distortion at high volume.
2. Optimized the frequency spectrum display effect and optimized the automatic adjustment function of the reference level.
3. Fixed the issue of the indicator light when radio is charging when turned off.
4. Fixed the issue of the antenna tunner.
5. Fixed the issue that unable to adjust the internal and external microphone volume.
6. Added 3 levels of spectrum bandwidth adjustment function.
7. Added low battery reminder function.
8. Added kHz bit adjustment, clear the bits of 100 Hz and below.

--- --- --- ---

X6100 is an ultra-portable shortwave transceiver. It adopts the SDR software radio platform architecture of excellent performance, which carries powerful baseband and RF unit, integrating rich and diversified operating functions, bringing you a brand-new recognition and experience on amateur radio. With its compact structure and tiny appearance, you can immediately set forth on a journey with it, get close to nature and enjoy the fun of outdoor communication.

- SDR Structure
- HF/50MHz Full Mode (supporting data communication)
- Transmitting Power: External power supply: 10W | Battery power supply: 5W
- 4" (3.46 x 2.13in) High-resolution Color Screen, 800*480
- Built-in 3000mAh Rechargeable Lithium Battery
- Built-in Automatic Antenna Tuner
- Integrated SWR Scanner & Voice Call
- Integrated Modem, Preset message, CW Automatic Call
- Built-in Bluetooth/Wifi function, enable wireless audio/keyboard/mouse operation
- Integrated USB control/transmission, supports USB HOST
- Built-in high-stability TCXO internal clock source

General Specifications
Frequency Receiving: 0.5MHz~30MHz | 50MHz~54MHz
Frequency Transmitting:
1.8~2.0MHz | 3.5~4.0MHz | 5.3MHz (60 Meters)
7.0~7.3MHz | 10.1~10.15MHz
14.0~14.35MHz | 18.068~18.168MHz
21.0~21.45MHz | 24.89~24.99MHz
28.0~29.7MHz | 50.00~53.99MHz
Operation Mode: USB/LSB (J3E), CW (A1A), FM (F3E), RTTY(F1B), AM (A3E)
Minimum Frequency step: 10Hz
Frequency Stability: ±1.5ppm
External Power Supply Voltage: DC 9.0V~15.0V, negative ground
Frequency Stability: ±1ppm (20 minutes after start)
Antenna Port Impedance: 50Ω
Antenna Interface Type: BNC
Working Temperature: 0℃~+55℃
Transmission power: External power supply: 10W | Battery power supply: 5W
Current consumption: Standby: 330mA (Max) | Transmit: 3A (Max)
Overall dimensions: About 7.1*3.4*2in | 180*86*49mm
Weight: about 1.94lb | 880g (host only)

Transmitting Power:
10W (SSB/CW/FM) @13.8VDC | 5W @battery
2.5W(AM) @13.8VDC | 1.5W @battery
Stray Suppression: 1.8~29.6MHz: ≥50dB | 50~54MHz: ≥60dB
Sideband Suppression: ≥50dB
Microphone Impedance: 200~10kΩ (600Ω in general)

Circuit Type: ZIF
Sideband Suppression: ≥50dB
MDS: -138dB

Band/Mode SSB/CW FM AM
0.5~1.79999MHz / / 10uV
1.8~1.99999MHz 0.35uV / 10uV
2.0~27.9999MHz 0.20uV / 2uV
28.0~30.0MHz 0.20uV 0.22uV 2uV
50.0 ~ 54.0MHz 0.20uV 0.22uV 2uV


Antenna Tuner
VSWR: 1:5.0
Antenna tuner initial tuning time: ≤15s
Antenna tuner tuning read time: ≤0.2s

Wireless network/Bluetooth
Wireless LAN standard: IEEE802.11b/g/n
Authentication and encryption: WEP (64/128bit)
Frequency band: 2.4G
Bluetooth version: 4.0

Note that the center pin is positive.
Note that as for the included power cable, the white one is positive and black one is negative.

What’s in the box?
1 x Xiegu X6100 Transceiver
1 x USB Type-C Data Cable
1 x Multi-function Speaker Mic
1 x Power Adapter
1 x Charging Cable
1 x User Manual

How to connect X6100 to XPA125B Amplifier?


X6100 can expand the output power to 100W when connected to the XPA125B power amplifier through a L4001 cable (not included).

After connection, X6100 can automatically control the band switching of XPA125B. At the same time, ALC control will be established between the two machines. When the power output from X6100 to XPA125B exceeds the limit, it will be automatically reduced, so that the output power of XPA125B is constant at about 100W.

We recommend you set the output power of X6100 to ≤2.5W to protect the power amplifier equipment.

Recommended Accessories (not included in the package)
1. Xiegu XPA125B 100W Power Amplifier & L4001 Cable
2. Xiegu GNR1 Digital Audio Noise Filter
